1、瓦斯發電機組尾氣的余熱利用簡介?對于瓦斯發電機組，瓦斯產生的能量只有30%—35%被轉化為電能，約有30%—35%隨高溫尾氣排出，約20%—25%被發動機自身冷卻系統帶走，約10%以機身散熱和阻力等其他損耗。瓦斯發電機組余熱利用就是通過專用設備將機組排出的高溫尾氣和冷卻系統帶走的熱量回收，再輸送到需要熱源的車間或居民小區

　　1. Introduction to the utilization of waste heat from exhaust gas of gas generator sets? For gas generator sets, only 30% -35% of the energy generated by gas is converted into electrical energy, about 30% -35% is discharged with high-temperature exhaust gas, about 20% -25% is taken away by the engine's own cooling system, and about 10% is used for other losses such as body heat dissipation and resistance. The utilization of waste heat from gas generator sets refers to the recovery of high-temperature exhaust gas and heat carried away by the cooling system through specialized equipment, and then transported to workshops or residential areas that require heat sources

　　。例如，國內廣泛使用的500KW低濃度瓦斯發電機組，其產生的高溫尾氣熱量經熱管空預器回收后，可向企業車間供熱風，或在冬季向煤礦風井巷道供熱風防止凍井；如果向辦公室、居民小區或浴室供熱，可加裝熱管換熱器（熱管省煤器），每臺換熱器可產生90℃以上的熱水近4噸/小時，解決4000m2以上建筑面積采暖或中型浴池洗浴。

　　. For example, the widely used 500KW low concentration gas generator set in China can provide hot air to enterprise workshops or supply hot air to coal mine ventilation shafts in winter to prevent freezing after the high-temperature exhaust heat generated is recovered by the heat pipe air preheater; If heating is provided to offices, residential areas, or bathrooms, heat pipe heat exchangers (heat pipe economizers) can be installed. Each heat exchanger can generate nearly 4 tons/hour of hot water above 90 ℃, solving the heating needs of buildings with an area of over 4000m2 or medium-sized bathhouses.

　　瓦斯發電機組產生的尾氣只要成分是CO2，溫度在550℃左右，通常情況下，每臺機組（500KW）產生的煙氣流量在2130Nm3/h以上。隨著瓦斯資源的深度開發，充分利用能源，合理利用瓦斯發電機組尾氣余熱是大勢所趨。?1.1、瓦斯發電機組余熱回收的工作原理?在瓦斯發電機組排氣系統安裝熱管余熱回收裝置，即熱管空預器（熱風利用）或熱管換熱器（熱水利用）或熱管蒸發器（低壓飽和蒸汽利用），通過熱動力循環設備（即大功率風機或熱水利用管道循環泵或蒸汽管道）將低溫交換介質（空氣或者軟化水）送到余熱回收裝置，經加熱的低溫交換介質變成熱源直接或者再次交換后輸送給終端客戶使用。

　　The exhaust gas generated by a gas generator set, as long as the component is CO2 and the temperature is around 550 ℃, usually produces a flue gas flow rate of 2130Nm3/h or more per unit (500KW). With the deep development of gas resources, it is the trend to fully utilize energy and make reasonable use of the waste heat from the exhaust gas of gas generators.? 1.1 Working principle of waste heat recovery for gas generator sets? Install a heat pipe waste heat recovery device in the exhaust system of a gas generator unit, namely a heat pipe air preheater (hot air utilization), heat pipe heat exchanger (hot water utilization), or heat pipe evaporator (low-pressure saturated steam utilization). The low-temperature exchange medium (air or softened water) is sent to the waste heat recovery device through a thermal power circulation device (i.e. high-power fan or hot water utilization pipeline circulation pump or steam pipeline), and the heated low-temperature exchange medium becomes a heat source and is directly or re exchanged before being transported to end customers for use.

　　1.2、瓦斯發電機組余熱回收的主要用途?余熱回收的方式根據各個企業所需要的熱源不同有空氣置換余熱、軟化水置換余熱產生熱水以及軟化水置換余熱產生蒸汽三種。余熱回收后的主要用途有以下幾種：（1）煤礦巷道暖井（風井供熱風）：在北方的冬季，煤礦風井巷道都需要熱風爐暖井。把低濃度瓦斯發電機組產生的高溫尾氣經過熱管空預器，將冷空氣加熱，可以得到高溫熱風通過煙道與風井處得熱管空預器再次換熱后的熱空氣送入風井，從而降低井下熱風爐的熱量輸出，節約電能。

　　1.2. What are the main uses of waste heat recovery in gas generator sets? The methods of waste heat recovery vary depending on the heat source required by each enterprise, including air replacement waste heat, softened water replacement waste heat to produce hot water, and softened water replacement waste heat to produce steam. The main uses of waste heat recovery are as follows: (1) coal mine tunnel heating (air shaft heating air): In winter in the north, coal mine air shaft tunnels require hot air stoves to warm the shafts. The high-temperature exhaust gas generated by the low concentration gas generator unit is passed through a heat pipe air preheater, and the cold air is heated to obtain high-temperature hot air. The hot air is then sent to the air shaft through the flue and the heat pipe air preheater for further heat exchange, thereby reducing the heat output of the underground hot air stove and saving electricity.

　?。?）烘干、采暖和洗浴用熱源：?企業生產工藝中的烘干、采暖和洗浴常年需要熱源。在發電機組煙道出口加裝一臺熱管換熱器（熱管省煤器），通過熱水循環泵幾個低溫水送到熱管換熱器，經過熱交換的軟化水為熱源（90℃以上）供給企業生產使用，冷卻后的軟化水在返回熱管換熱器，如此往復循環。?（3）余熱制冷：目前廣泛采用溴化鋰吸收式制冷。用熱管蒸發器吸收低濃度瓦斯發電機組余熱回收的熱量。

　　(2) Drying, heating, and bathing heat sources:? Drying, heating, and bathing in enterprise production processes require heat sources year-round. Install a heat pipe heat exchanger (heat pipe economizer) at the outlet of the generator set flue, and send several low-temperature water to the heat pipe heat exchanger through a hot water circulation pump. The softened water after heat exchange is used as a heat source (above 90 ℃) for enterprise production, and the cooled softened water returns to the heat pipe heat exchanger, repeating the cycle.? (3) Waste heat refrigeration: Currently, lithium bromide absorption refrigeration is widely used. Use a heat pipe evaporator to absorb the heat recovered from the waste heat of a low concentration gas generator set.

　?。?）余熱發電：通過多臺瓦斯發電機組尾氣的余熱回收，安裝熱管蒸發器，產生的飽和蒸汽并往后拖動汽輪機組進行二次發電，發電后的冷凝水亦可制冷或者供暖，給企業帶來可觀的經濟效益。

　　(4) Waste heat power generation: By recovering the waste heat from the exhaust gas of multiple gas generator units, installing heat pipe evaporators, and generating saturated steam, the steam turbine units are then driven for secondary power generation. The condensed water after power generation can also be used for cooling or heating, bringing considerable economic benefits to the enterprise.
