The generator set is a complete set of mechanical equipment that converts other forms of energy into electric energy. It has low oil consumption, low emissions, low noise, advanced technology, reliable work, convenient maintenance, long service life, lightweight portability, high emergency efficiency, and low comprehensive cost. It is widely used in industrial and agricultural production, national defense, science and technology and daily life.

近年來隨著技術進步，作為家庭應急電源及野外出行電源的選擇，由于發電機組本身所能供電范圍有限，且使用場所可以方便更換；雷雨天氣可以放置于戶內，但有些時候發電機組是需要在戶外使用的，遇到惡劣的天氣就會涉及到設備的防雷保護，那么發電機組的防雷保護需要有哪些具體的步驟呢？

In recent years, with the progress of technology, as the choice of household emergency power supply and outdoor travel power supply, the power supply range of the generator set itself is limited, and the place of use can be easily replaced; In thunderstorm weather, the generator set can be placed indoors, but sometimes it needs to be used outdoors. In case of bad weather, the lightning protection of the equipment will be involved. What specific steps should be taken for the lightning protection of the generator set?

需要確定發電機組的防雷保護方式主要應根據發電機容量的大小、當?shù)乩纂娀顒?dòng)的強弱和對供電可靠性的要求。

Firstly, it is necessary to determine the lightning protection mode of the generator set mainly according to the size of the generator capacity, the strength of local lightning activities and the requirements for power supply reliability.

理論和實踐證明，經過變壓器再與架空輸電線連接的發電機組，只要可靠地保護了變壓器，一般就不需要對發電機組再采取防雷保護措施，在多雷區，無架空直配線的特別重要的發電機組，為防止變壓器高壓側的雷電波經過變壓器危及發電機的絕緣，宜在發電機的出線上裝設一組磁吹避雷器。

Theory and practice have proved that as long as the transformer is reliably protected for the generator set connected to the overhead transmission line through the transformer, it is generally unnecessary to take lightning protection measures for the generator set. In the lightning prone area, for the particularly important generator set without overhead direct wiring, in order to prevent the lightning wave at the high voltage side of the transformer from passing through the transformer and endangering the insulation of the generator, a group of magnetic blow arresters should be installed on the outgoing line of the generator.

直接與架空配電線路連接的發電機組進行防雷保護，應根據國家標準設計規范的規定，按不同情況對發電機組絕緣采取不同的防雷保護措施。保護高壓旋轉電機用的避雷器，一般采用磁吹避雷器，避雷器宜靠近發電機組。在一般情況下，避雷器可裝在電機出線處；

For lightning protection of generator units directly connected with overhead distribution lines, different lightning protection measures shall be taken for generator unit insulation according to different conditions according to the provisions of national standard design specifications. The lightning arrester used to protect high-voltage rotating motor generally adopts magnetic blowing lightning arrester, which should be close to the generator set. In general, the lightning arrester can be installed at the outlet of the motor;

如接在每一組母線上的發電機不超過兩臺，或單機容量不超過500kw，且與避雷器的距離不超過50m時，避雷器也可裝在每一組母線上當直配電機中性點能引出且未直接接地時，應在中性點上裝設磁吹或普通閥型避雷器。戶外使用發電機組一定要注意防雷，確保人身安全。

If no more than two generators are connected to each group of buses, or the single unit capacity is no more than 500kw, and the distance from the arrester is no more than 50m, the arrester can also be installed on each group of buses. When the neutral point of the direct distribution motor can be led out and is not directly grounded, the magnetic blow or ordinary valve type arrester should be installed on the neutral point. When using generator set outdoors, pay attention to lightning protection to ensure personal safety.

很多客戶購買柴油發電機組作為備用電源，一年才會用上幾次。如果柴油發電機組處于長期停運狀態不進行正確保養，將會導致需要使用時卻發現發電機啟動不了。那么柴油發電機組處于長期停運狀態，有什么需要注意的事項呢？

Many customers buy diesel generator sets as standby power supply, which can only be used several times a year. If the diesel generator set is shut down for a long time without proper maintenance, it will be found that the generator cannot be started when it is needed. So what should we pay attention to when the diesel generator set is in a long-term shutdown state?

一、封存前

1、 Before sealing

1、在一次柴油發電機組使用后，在熱態下放盡柴油發電機組潤滑油，包括機油濾清器中的機油。因冷卻液具有防銹功能，不需要排放。向曲軸箱內加入合格的規定容量的封存油，起動柴油發電機組至怠速，運轉1-1.5min即行停車，然后從油底殼中放出封存油。發動機內部封存油為經脫水的CF級15W/40潤滑油。

1. After the primary diesel generator set is used, drain the lubricating oil of the diesel generator set in the hot state, including the oil in the oil filter. As the coolant has rust prevention function, it does not need to be drained. Fill the crankcase with qualified sealing oil of specified capacity, start the diesel generator set to idle speed, run for 1-1.5 min and then stop the engine, and then drain the sealing oil from the oil pan. The sealing oil inside the engine is the dehydrated CF grade 15W/40 lubricating oil.

2、清理干凈柴油發電機組表面，檢查無可見的臟物、油污、銹跡、水跡等，然后用壓縮空氣吹干；用毛刷將防銹油均勻涂在所有柴油發電機組金屬表面機加工表面（即未噴漆的機加工表面）上；注意橡膠件、塑料件及纖維織物類零件表面禁止涂防銹油或防銹油接觸。

2. Clean the surface of the diesel generator set, check that there is no visible dirt, oil stain, rust, water stain, etc., and then dry it with compressed air; Use a brush to evenly apply the antirust oil on the machined surface of all the metal surfaces of the diesel generator set (that is, the unpainted machined surface); Note that the surface of rubber parts, plastic parts and fiber fabric parts shall not be coated with antirust oil or contacted with antirust oil.

注意：附件驅動帶輪表面需采取一定防銹措施。

Note: certain rust prevention measures shall be taken for the surface of accessory drive pulley.

發動機外部封存推薦使用FD615脫水防銹油或滿足下面性能要求的防銹油。

FD615 dehydrated antirust oil or antirust oil meeting the following performance requirements is recommended for engine external storage.

3、斷開蓄電池連接線，清潔端子，涂上一層薄油脂，給蓄電池充電。

3. Disconnect the battery connecting wire, clean the terminal, apply a thin layer of grease to charge the battery.

4、使傳動膠帶松弛

4. Slack the drive belt

5、將所有外露氣管、水管或油管管口用防潮紙或氣相防銹紙或聚乙烯塑料薄膜膠帶進行封口或包扎，整個空氣濾清器也應由防潮紙封口或包扎。

5. All exposed air pipes, water pipes or oil pipe orifices shall be sealed or wrapped with moisture-proof paper or vapor phase rust proof paper or polyethylene plastic film tape, and the entire air filter shall also be sealed or wrapped with moisture-proof paper.

二、保存期間

2、 Saving period

每月進行蓄電池充電。檢查蓄電池液面，需要時，添加，然后進行充電。每月用盤車工具盤動曲軸3-4圈。

Charge the battery every month. Check the liquid level of the battery, add it if necessary, and then charge it. Turn the crankshaft 3-4 times a month with the turning tool.

以上就是為大家介紹的有關煉化尾氣發電機組的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://www.dgtmcnc.com

The above is a detailed introduction to the refining tail gas generator set, and we hope it will be helpful to you. If you have any questions, please contact us. We will provide services for you with our attitude http://www.dgtmcnc.com
