During the process of replacing the fuel filter, high-pressure oil pipe, oil pump, etc. in the fuel system of the generator set, or when the fuel pipe is not sealed and the fuel is used up, the fuel system may enter the air during this period. If the air enters the fuel system, the unit will be difficult to start or the operation will be unstable, so it is necessary to exhaust the unit, so how to eliminate the air? Now let's introduce it to you by the editor of Cornwall.

一、排除空氣的方法

1、 Method of removing air

1、一般情況下，用起子或扳手?jǐn)Q松噴油泵兩側上端的任一排氣螺絲數圈。用手按壓手動油泵15-20次，至排出的柴油連續通暢無氣泡，發出“吱吱”的聲音為止。擰死放氣螺釘，將手動油泵按壓回至原位。

1. Generally, loosen any exhaust screw at the upper end of both sides of the fuel injection pump with a screwdriver or wrench for several turns. Press the manual oil pump for 15-20 times until the discharged diesel oil is continuous and free of bubbles and makes a "squeak" sound. Tighten the vent screw and press the manual oil pump back to its original position.

2、如果手頭沒有打開噴油泵上放氣螺釘?shù)暮线m起子或扳手，可先擰開手油泵，然后松開從柴油濾清器至噴油泵之間的任何一個管接頭，然后再通過反復按壓手油泵至從該接頭中排出通暢無氣泡的油流即可，然后邊按壓手油泵邊緊固該接頭，然后再將手油泵撳壓回原位即可。

2. If there is no suitable driver or wrench to open the vent screw on the fuel injection pump, first unscrew the hand oil pump, then loosen any pipe joint from the diesel filter to the fuel injection pump, and then press the hand oil pump repeatedly until a smooth and bubble free oil flow is discharged from the joint, then tighten the joint while pressing the hand oil pump, and then press the hand oil pump back to its original position.

3、如果手頭無松開管路中接頭的扳手時，可以通過反復的按壓你的手油泵，至輸油泵到噴油泵段低壓油路壓力足夠高時，燃油從溢流閥中流入燃油回油管路，油路中的氣體就會從溢流閥中排出。

3. If there is no wrench to loosen the connector in the pipeline, you can press your hand oil pump repeatedly until the pressure of the low-pressure oil path from the oil delivery pump to the fuel injection pump section is high enough, the fuel flows into the fuel return pipeline from the overflow valve, and the gas in the oil path will be discharged from the overflow valve.

4、如果在途中，需要排除油路中的空氣，可以先松開噴油泵上的放氣螺釘或松開柴油濾清器與噴油泵之間的任意一個接頭，然后通過起動驅動機械輸油泵。該漏點就會噴出通暢且無氣泡的燃油，這時再擰緊松開的上述漏點就可以了。

4. If the air in the oil path needs to be removed on the way, loosen the bleed screw on the fuel injection pump or loosen any connector between the diesel filter and the fuel injection pump, and then drive the mechanical fuel transfer pump by starting. The leak point will eject unobstructed and bubble free fuel. At this time, it is OK to tighten the loosened leak point.

二、注意事項

2、 Precautions

1、不可在柴油機熱機狀態排氣，燃油如果噴到熾熱排氣管上，將會造成火災。

1. Do not exhaust when the diesel engine is hot. If fuel is sprayed on the hot exhaust pipe, it will cause a fire.

2、應防止高壓燃油損傷皮膚。

2. High pressure fuel shall be prevented from damaging skin.

3、裝有通電型斷油閥的發電機組燃油系統的排氣時，一定要先將控制屏內標。

3. When exhausting the fuel system of the generator set equipped with the energizing fuel cut-off valve, the control panel must be marked inside.

4、有“FCR”中間繼電器上的按鈕拔出后再開始排氣操作，排氣結束后要將“FCR”中間繼電器上的按鈕壓下復位。

4. After the button on the "FCR" intermediate relay is pulled out, the exhaust operation can be started. After the exhaust, press the button on the "FCR" intermediate relay to reset.

5、油路排氣時，用扳手?jǐn)Q松各處排氣螺釘，上下扳動輸油泵手柄泵油，直至出油中沒有氣泡后擰緊排氣螺釘即可。

5. When the oil circuit is vented, loosen the vent screws with a wrench, pull the handle of the oil transfer pump up and down to pump oil until there are no bubbles in the oil outlet, and then tighten the vent screws.

6、一般經過低壓油路的排除空氣，機組就可啟動。如還需要排除高壓油管中的空氣，松開高壓油管在噴油器一端的螺帽，按壓手動油泵，直至所溢出的燃油中無氣泡后擰緊螺帽。如此逐缸進行，使各缸噴油器中充滿燃油。

6. Generally, the unit can be started after the air is discharged through the low-pressure oil circuit. If it is necessary to remove the air from the high-pressure oil pipe, loosen the nut of the high-pressure oil pipe at one end of the fuel injector, press the manual oil pump until there are no bubbles in the spilled fuel, and then tighten the nut. This is done cylinder by cylinder so that the fuel injectors of each cylinder are filled with fuel.

7、如果氣體仍不能排凈，應檢查管路是否有漏氣情況。

7. If the gas cannot be discharged completely, check whether there is air leakage in the pipeline.
